Stage Box
32 Inputs, 16 Outputs, 48kHz
Yamaha Rio 3224-D
Description
The Yamaha Rio 3224-D is a rugged and dependable Dante-enabled I/O stage box built for high-end audio systems. Ideal for festivals, corporate events, and touring shows, it features 32 inputs and 16 outputs, providing smooth integration with Yamaha CL and QL series digital mixers. With superior audio quality and flexible network routing, the Rio 3224-D is an essential addition to any live event audio setup.
š Key Features
š¹ 32 analog XLR inputs with transparent Yamaha mic preamps
š¹ 16 XLR outputs for flexible audio routing
š¹ Seamless Dante audio networking for low-latency, high-resolution digital transmission
š¹ Dual network ports for redundant Dante operation
š¹ Compatible with Yamaha CL, QL, and TF series digital consoles
š¹ Gain Compensation ensures stable levels with multiple devices
š¹ 96 kHz sampling support for studio-grade performance
š¹ Durable 3U rackmount chassis suitable for touring and permanent installs
š Ready to streamline your stage connectivity? Rent the Yamaha Rio 3224-D now for your next big event!
Add to cart
Yamaha Rio 3224-D Specification
š¹ Type: Dante-enabled digital stage box
š¹ Sound Philosophy: Natural Sound Concept, inherits PM series sonic quality
š¹ Sampling Rates: 44.1 / 48 / 88.2 / 96 kHz
š¹ Analog Inputs: 32 x XLR (XLR-3-31 type)
š¹ Analog Outputs: 16 x XLR
š¹ AES/EBU Outputs: 8 (4 stereo)
š¹ Indicators: Signal, Peak, +48V
š¹ Gain Compensation: Supported
š¹ HA Control Redundancy (CL/QL): Supported
š¹ Remote Control: Supported via R Remote software
š¹ Max HA Remote Units: Up to 8 per system
š¹ AD8HR Mode (M7CL/LS9): Supported
š¹ External Clock Tolerance: Ā±200 ppm across supported sample rates
š¹ Signal Delay: <3 ms (with CL5 and Dante @ 48kHz, 0.25 ms latency)
š¹ THD: <0.05% (20Hzā20kHz @ Fs=44.1/48kHz, and 20Hzā40kHz @ Fs=88.2/96kHz)
š¹ Frequency Response: +0.5/-1.5 dB (20Hzā20kHz @ 44.1/48kHz; 20Hzā40kHz @ 88.2/96kHz)
š¹ Dynamic Range: 108 dB (typical, Input Gain = Min)
š¹ Crosstalk: -100 dB (adjacent channels, Input Gain = Min)
š¹ Power Requirements:
āāā¢ US/Canada: 120V 60Hz
āāā¢ Japan: 100V 50/60Hz
āāā¢ China/Other: 110ā240V 50/60Hz
āāā¢ Korea: 220V 60Hz
š¹ Power Consumption: 120W
š¹ Operating Temp Range: 0Ā°C to 40Ā°C
š¹ Storage Temp Range: -20Ā°C to 60Ā°C
š¹ AC Inlet: V-lock type
š¹ Rack Height: 5U
š¹ Dimensions: 480 x 232 x 362 mm
š¹ Weight: 12.4 kg
š§ Enhance your stage input/output count with the reliable Rio 3224-D ā rent now and stay in sync with Yamaha systems!
š For more details on Yamaha Rio 3224-D specifications, click here.
