Flying Sub
passive single 18" cardioid
d&b Audiotechnik Y Sub
Description
High-impact low-end performance in a compact, flyable form
Take your event’s audio to the next level with the d&b audiotechnik Y-SUB, a cardioid subwoofer designed for clarity, punch, and flexible deployment. Engineered for high SPL output and precise low-frequency control, this subwoofer is perfect for concerts, festivals, and corporate events where space and sound matter equally.
🔑 Key Features:
🔹 Cardioid design for reduced rear sound emissions
🔹 Flyable subwoofer – perfect for flown and ground-stacked configurations
🔹 High output of up to 134 dB SPL with D80/D40 amplifiers
🔹 Flexible splay angles (0° and 2.5°) for tailored array configurations
🔹 Dual driver design with 18" and 12" neodymium speakers for precision and depth
🔹 Durable build ideal for touring and large-scale events
💡 Perfect for adding deep, controlled bass to your audio setup without compromising on space or setup time.
Add to cart
d&b Audiotechnik Y Sub Specification
🔹 Frequency Response (–5 dB Standard): 39 Hz – 140 Hz
🔹 Frequency Response (–5 dB 100 Hz Mode): 39 Hz – 110 Hz
🔹 Max. Sound Pressure Level:
  – 128 dB with 10D
  – 131 dB with D20 / 30D
  – 134 dB with D40 / D80 / 40D2
🔹 Cabinets per Amp Channel: 2
🔹 Configuration: High-performance cardioid subwoofer (flyable)
🔹 Nominal Impedance: 8 Ω
🔹 Power Handling (RMS / Peak 10 ms): 600 W / 2400 W
🔹 Splay Angle Options: 0° and 2.5°
🔹 Components:
  – 1 x 18" neodymium driver
  – 1 x 12" neodymium driver
🔹 Connections: 2 x NLT4 F/M
🔹 Dimensions (H x W x D): 500 x 630 x 700 / 804 mm
  (19.7 x 24.8 x 27.6 / 31.6 in)
🔹 Weight: 52 kg (115 lb)
✅ Rent the d&b Y-SUB Today!
Looking for deep, directional bass that fits your flyable setup? Rent the d&b audiotechnik Y-SUB now and elevate your sound system with power and precision.
