Line Array Cabinet
3-way passive, Dual 10"
d&b Audiotechnik V8
Description
Rent the d&b Audiotechnik V8 in Dubai – High-performance sound, built for big stages!
The d&b V8 Line Array Cabinet is a dual 10" 3-way passive loudspeaker designed for exceptional clarity and coverage. Whether you're powering up a concert, corporate event, or festival, this compact yet powerful line array delivers punchy mids, smooth highs, and thunderous lows when paired with d&b amplifiers. With its innovative design and flexible splay angles, the V8 provides precise horizontal and vertical dispersion, making it ideal for touring and professional applications.
🔑 Key Features
🔹 Compact 3-way passive line array with dual 10" drivers
🔹 Delivers up to 142 dB SPL with premium d&b amplifiers
🔹 Flexible splay angle from 0° to 14° in 1° steps
🔹 High-performance audio with detailed mids and crisp highs
🔹 Durable construction ideal for touring and live productions
🔹 Compatible with D20, 30D, D40, and D80 amps
🔹 Rugged connections with NLT4 and optional NL4 options
🎧 Perfect for: Concerts, stadiums, festivals, large-scale events
📦 Pair with d&b subs and amps for a complete professional audio system!
Add to cart
d&b Audiotechnik V8 Specification
🔹 Frequency response (-5 dB standard): 67 Hz – 18 kHz
🔹 Frequency response (-5 dB CUT mode): 100 Hz – 18 kHz
🔹 Max. sound pressure: 139 dB with D20/30D, 142 dB with D40/D80/40D
🔹 Cabinets per amplifier channel: 2
🔹 Configuration: High-performance 3-way passive line array loudspeaker
🔹 Nominal impedance: 8 Ω
🔹 Power handling capacity (RMS/peak 10 ms): 500 / 2000 W
🔹 Nominal dispersion angle (horizontal): 80°
🔹 Splay angle settings: 0° – 14° (1° increments)
🔹 Components: 2 x 10" drivers / 1 x 8" driver / 2 x 1.4" exit compression drivers
🔹 Connections: 2 x NLT4 F/M, optional 2 x NL4
🔹 Dimensions (H x W x D): 310 x 700 x 460 mm – 12.2 x 27.5 x 18"
🔹 Weight: 34 kg / 75 lb
✅ Book the d&b Audiotechnik V8 Today!
Bring concert-grade clarity and power to your event. Rent now and make your sound unforgettable!
